-- TGMS Nampally: database schema for Supabase (PostgreSQL) -- Run in Supabase > SQL Editor. Roles: principal, teacher, office, parent. -- Student data belongs to minors: RLS is ON everywhere; nothing personal is public. create table profiles ( id uuid primary key references auth.users(id) on delete cascade, full_name text not null, role text not null check (role in ('principal','teacher','office','parent')), created_at timestamptz default now() ); create table classes ( id serial primary key, name text unique not null -- e.g. 'Class 6', 'Inter 1st year - MPC' ); create table students ( id uuid primary key default gen_random_uuid(), admission_no text unique not null, full_name text not null, class_id int references classes(id), section text, dob date, gender text check (gender in ('M','F','O')), guardian_name text, guardian_phone text, parent_user uuid references profiles(id), -- login of the parent, if any active boolean default true, created_at timestamptz default now() ); create table attendance ( id uuid primary key default gen_random_uuid(), student_id uuid not null references students(id) on delete cascade, day date not null, status text not null check (status in ('present','absent','leave')), marked_by uuid references profiles(id), unique (student_id, day) ); create table exams ( id uuid primary key default gen_random_uuid(), name text not null, class_id int references classes(id), exam_date date ); create table marks ( id uuid primary key default gen_random_uuid(), exam_id uuid not null references exams(id) on delete cascade, student_id uuid not null references students(id) on delete cascade, subject text not null, marks numeric, max_marks numeric default 100, unique (exam_id, student_id, subject) ); create table notices ( id uuid primary key default gen_random_uuid(), title text not null, title_te text, body text, file_url text, is_public boolean default false, published_at timestamptz default now(), created_by uuid references profiles(id) ); create table applications ( -- admission enquiries from the public form id uuid primary key default gen_random_uuid(), student_name text not null, phone text not null, class_or_group text, message text, status text default 'new' check (status in ('new','contacted','selected','rejected','joined')), created_at timestamptz default now() ); create table certificate_requests ( id uuid primary key default gen_random_uuid(), student_id uuid not null references students(id), kind text not null check (kind in ('bonafide','tc')), status text default 'pending' check (status in ('pending','issued','rejected')), requested_by uuid references profiles(id), created_at timestamptz default now() ); create table audit_log ( id bigserial primary key, user_id uuid, action text, table_name text, row_id text, at timestamptz default now() ); -- ---------- helpers ---------- create function auth_role() returns text language sql stable security definer set search_path = public as $$ select role from profiles where id = auth.uid() $$; create function audit() returns trigger language plpgsql security definer set search_path = public as $$ begin insert into audit_log(user_id, action, table_name, row_id) values (auth.uid(), tg_op, tg_table_name, coalesce(to_jsonb(new)->>'id', to_jsonb(old)->>'id')); return coalesce(new, old); end $$; -- call from the app whenever a student record is opened (views cannot be caught by triggers) create function log_view(student uuid) returns void language sql security definer set search_path = public as $$ insert into audit_log(user_id, action, table_name, row_id) values (auth.uid(), 'VIEW', 'students', student::text) $$; create trigger a_students after insert or update or delete on students for each row execute function audit(); create trigger a_marks after insert or update or delete on marks for each row execute function audit(); create trigger a_attendance after insert or update or delete on attendance for each row execute function audit(); create trigger a_certs after insert or update or delete on certificate_requests for each row execute function audit(); -- ---------- row-level security ---------- alter table profiles enable row level security; alter table classes enable row level security; alter table students enable row level security; alter table attendance enable row level security; alter table exams enable row level security; alter table marks enable row level security; alter table notices enable row level security; alter table applications enable row level security; alter table certificate_requests enable row level security; alter table audit_log enable row level security; create policy profiles_self on profiles for select using (id = auth.uid() or auth_role() = 'principal'); create policy profiles_admin on profiles for all using (auth_role() = 'principal') with check (auth_role() = 'principal'); create policy classes_read on classes for select using (auth.uid() is not null); create policy classes_write on classes for all using (auth_role() in ('principal','office')) with check (auth_role() in ('principal','office')); create policy students_staff_read on students for select using (auth_role() in ('principal','teacher','office')); create policy students_parent_read on students for select using (parent_user = auth.uid()); create policy students_write on students for all using (auth_role() in ('principal','office')) with check (auth_role() in ('principal','office')); create policy att_staff on attendance for select using (auth_role() in ('principal','teacher','office')); create policy att_parent on attendance for select using (student_id in (select id from students where parent_user = auth.uid())); create policy att_write on attendance for all using (auth_role() in ('principal','teacher','office')) with check (auth_role() in ('principal','teacher','office')); create policy exams_read on exams for select using (auth.uid() is not null); create policy exams_write on exams for all using (auth_role() in ('principal','teacher')) with check (auth_role() in ('principal','teacher')); create policy marks_staff on marks for select using (auth_role() in ('principal','teacher','office')); create policy marks_parent on marks for select using (student_id in (select id from students where parent_user = auth.uid())); create policy marks_write on marks for all using (auth_role() in ('principal','teacher')) with check (auth_role() in ('principal','teacher')); create policy notices_public on notices for select using (is_public = true); create policy notices_staff on notices for select using (auth_role() in ('principal','teacher','office')); create policy notices_write on notices for all using (auth_role() in ('principal','office')) with check (auth_role() in ('principal','office')); create policy apps_insert on applications for insert to anon, authenticated with check (true); -- public enquiry form create policy apps_staff on applications for select using (auth_role() in ('principal','office')); create policy apps_update on applications for update using (auth_role() in ('principal','office')); create policy certs_staff on certificate_requests for all using (auth_role() in ('principal','office')) with check (auth_role() in ('principal','office')); create policy certs_parent_read on certificate_requests for select using (requested_by = auth.uid()); create policy certs_parent_insert on certificate_requests for insert with check (requested_by = auth.uid()); create policy audit_principal on audit_log for select using (auth_role() = 'principal'); -- ---------- dummy seed data (replace before going live) ---------- insert into classes(name) values ('Class 6'),('Class 7'),('Class 8'),('Class 9'),('Class 10'), ('Inter 1st year - MPC'),('Inter 1st year - BiPC'),('Inter 1st year - CEC'),('Inter 1st year - ACE'), ('Inter 2nd year - MPC'),('Inter 2nd year - BiPC'),('Inter 2nd year - CEC'),('Inter 2nd year - ACE'); insert into students(admission_no, full_name, class_id, section, gender, guardian_name, guardian_phone) select 'DUMMY-'||g, 'Sample Student '||g, (g % 5) + 1, 'A', 'O', 'Sample Guardian '||g, '0000000000' from generate_series(1,6) g; insert into notices(title, title_te, body, is_public) values ('Sample notice: Admissions open', 'నమూనా నోటీసు: ప్రవేశాలు ప్రారంభం', 'Replace with the real notice.', true), ('Sample notice: Examination timetable', 'నమూనా నోటీసు: పరీక్షల టైమ్‌టేబుల్', 'Replace with the real notice.', true); -- After creating your own login in Supabase > Authentication, make yourself the principal: -- insert into profiles(id, full_name, role) values ('', 'G. Bhagyalakshmi', 'principal');
